LD Systems MAUI 28 G3 MIX Portable 2060W Powered Column PA System (Black)
- SKU
- MAUI28G3MIX
- Barcode
- 4049521914256
- For DJs, Singer-Songwriters, Small Bands
- Bluetooth Audio with Stereo Streaming
- Powered Subwoofer Module with Sat Out
- 4-Input, 6-Channel Mixer with AEQ and FX
Overview
LD Systems MAUI 28 G3 MIX Portable 2060W Powered Column PA System (Black) by LD Systems, model MAUI28G3MIX. Listed under PA Systems in our Audio Visual range.
Weight: System: 79.8 lb / 36.2 kg (Full Assembly) Subwoofer: 52 lb / 23.6 kg Top Speaker: 27.8 lb / 12.6 kg.
Key features
- For DJs, Singer-Songwriters, Small Bands
- Bluetooth Audio with Stereo Streaming
- Powered Subwoofer Module with Sat Out
- 4-Input, 6-Channel Mixer with AEQ and FX
- Twelve Midrange 3.5″ and Two 1″ Tweeters
- 120 x 30° Coverage, 37 Hz to 20 kHz
Specifications
Portable PA System
| Speaker Configuration | 1x 3-Way Speaker Column with Subwoofer |
|---|---|
| Number of Input Channels | 2 (2 x Mono) |
| Amplifier Power Rating | 1030 W RMS 2060 W Peak |
| Amplifier Class | Class-D |
Speakers
| Enclosure Type | Bass-Reflex |
|---|---|
| HF Driver | 2x 1" / 25.4 mm Horn-Loaded Tweeter |
| HF Voice Coil | 1" / 25.4 mm |
| MF Driver | 12x 3.5" / 88.9 mm |
| MF Voice Coil | 0.75" / 19.05 mm |
| Subwoofer Driver | 1x 12" / 304.8 mm Woofer |
| Subwoofer Voice Coil | 3" / 76.2 mm |
| Magnet | HF Driver: Neodymium MF Driver/Subwoofer: Ferrite |
Signal Processing
| Input Pad | No |
|---|---|
| AEQ | Yes |
| Effects | Yes |
| DSP | 24-Bit DSP at 48 kHz |
| Dynamic Processing | Multiband Limiter |
Performance
| Frequency Response | 37 Hz to 20 kHz |
|---|---|
| Maximum SPL | 127 dB |
| Coverage Angle | 120° H x 30° V |
| Protections | DC Fault, Output Limiter, Short Circuit, Thermal |
Connectivity
| Audio I/O | 4x Combo XLR-1/4" 3-Pin Female Balanced/Unbalanced Line Input 2x XLR 3-Pin Male Balanced Monitor Output 1x XLR 3-Pin Male Balanced Mix Output 1x 1/4" TS Female Footswitch Input |
|---|---|
| USB I/O | No |
| Mobile App Compatible | Yes: Android & iOS App Name: MAUI G3 Mix Functionality: Adjust Settings, Remote Control, Setup, View Live Feed |
| Network I/O | No |
| Wireless Connectivity | Bluetooth |
| Bluetooth | 5.0 |
| Bluetooth Profiles | A2DP |
Power
| AC Input Power | 100 to 120 VAC, 50 / 60 Hz (T 5 A L 250 V) 220 to 240 VAC, 50 / 60 Hz (T 5 A L 250 V) |
|---|---|
| Power Consumption | 400 W |
| AC Power I/O | 1x IEC Input |
Physical
| Transport Options | Subwoofer: 1x Handle (Top) |
|---|---|
| Cooling | Convection |
| Construction Material | Aluminium, Plywood, Polyurethane |
| Environmental Resistance | No |
| Dimensions | System: 80.8" / 2052 mm (Full Assembly) Subwoofer: 20.7 x 18.6 x 14.6" / 527 x 472 x 370 mm Top Speaker: 60.6 x 5.3 x 4.1" / 1540 x 135 x 103 mm |
| Weight | System: 79.8 lb / 36.2 kg (Full Assembly) Subwoofer: 52 lb / 23.6 kg Top Speaker: 27.8 lb / 12.6 kg |
In the box
- LD Systems MAUI 28 G3 MIX Portable 2060W Powered Column PA System (Black)
- 2 x Column Speakers
- Subwoofer
- Power Cord
